INEFIL AL5%MG - 5356

Solid wire for welding aluminum 5% magnesium alloy 5356

Solid wire for welding aluminum-magnesium-based alloys with a maximum content of 5%

Classifications
  • AWS A 5.10: ER5356
  • EN ISO 18273: S AlMg5Cr(A)
  • EN ISO 18273: S Al 5356
Approvals
  • Marchio CE
Description + -

Solid wire designed for welding aluminum alloys with a magnesium content up to 5%. It finds application in car and rail fabrication and electro - domestic appliance. The weld material shows an excellent resistance to corrosion. To be used under the shield of Argon.

Typical chemical analysis (Wire wt%) + -
Mn 0.15
Mg 5.00
Fe 0.13
Cr 0.14
Al Bal.
Typical mechanical characteristics + -
I1
Yield strength 110 MPa
Tensile strength 240 MPa
Elongation 17 %
Welding parameters + -
Diameter (mm) Volts
0.8
1.0
1.2
Welding positions + -

ALL
